Deer Creek AMD Treatment System

Deer Creek AMD Treatment System

Project Details
Original Construction Year 2017
Most Recent Rebuild Year
Total Cost 0.00
Total Capital Cost $837,097.60
Latitude / Longitude Method Unknown
Latitude 41.086784
Longitude -78.262439
Project Deer Creek AMD Treatment System
Project Type Passive Treatment System
Project Status Good/Operational
AMD Source Underground
Stream Deer Creek
River Basin Susquehanna
Quad Lecontes Mills NE
City/Township Lecontes Mills / Girard
County Clearfield
State PA

Description: The purpose of this project was to construct a passive treatment system on the "School Trib" (Trib #4) in the Deer Creek watershed approximately 3 miles southwest of Frenchville on Route 879. The length of Trib #4 is impacted by numerous AMD seeps from past deep mining activities. Rather than tackle each discharge individually, we chose to construct this treatment system in a downstream area where the flow from all these separate discharges has combined and can be treated together at one location. The treatment layout consists of a mixing basin, vertical flow pond 1, settling basin 1, vertical flow pond 2, and final settling basin with final discharge through a riprap lined spillway and back into the Unnamed Tributary to Deer Creek. In addition to the AMD Passive Treatment System this project also included a Step-Pool type treatment system for existing impacted stormwater drainage that crosses the site but could not be directed into the main system due to elevation differences. The Step-Pool system is constructed at the east end of the AMD treatment system. This system offers some treatment to the impacted run-off waters that flow through the site into the Unnamed Tributary to Deer Creek. Treatment within the Step-Pool includes limestone, organic media, and aeration.

Water Quality Data Summary

Treatment Technologies
Treatment Technology Quantity Status
Forebay 1 N/A
Open Limestone Channel (OLC) 1 N/A
Settling Pond 2 N/A
Step Pool Limestone Compost Cells 1 N/A
Vertical Flow Pond (VFP) 2 N/A
Location Links
GPS Directions
Project Contacts
Contact Person: kwilliamsccd
Contact Organization: Clearfield County Conservation District
Project Designer:
Project Designer Organization: WHM Associates
Project Responsible Organization: Clearfield County Conservation District
no data available
External System IDs
no data available
Project Performance
